The ELZU external belt driven actuator consists of two Y-axes and single X-axis, driven by one rotating belt. This belt runs around different deflection pulleys. Positioning is achieved by two motors. The coordinate is diagonal to the deflection points of the Y-axis. Advantage: A smaller amount of inertia is needed, thus enabling high accelerations to be achieved.
The ELZU belt driven actuator is available in multiple configurations;
X-Axis Wrap Around Carriage (WAC) Only
Both X-Axis and Y-Axis Wrap Around Carriages (WAC)
